Yamaha DBR15 Active speaker is the largest in the DBR Series of speakers. DBR Series powered loudspeakers harness the same state-of-the-art Yamaha DSP, amplifier and speaker technologies developed for the professional DSR Series and DXR Series lineups, ensuring high-resolution sound at any output level. Meet the Yamaha DBR 15 Active speaker - the 15~ workhorse in the DBR Range, an active top perfect for any musicla performer or DJ. The Yamaha DBR15 Active speaker achieves best-in-class SPL of up to132dB and delivers the lowest frequency in its lineup. The DBR15 delivers outstanding performance for the main front-of-house sound for the live performance or DJ events that require highly prominent low and more power.
Specs:
Speaker type 2-way, Bi-amp powered speaker, Bass-reflex type
Frequency range (-10dB) 50Hz – 20kHz
Nominal coverage H 90°
V 60°
Components LF Diameter:15" cone, Voice Coil:2.5", Magnet:Ferrite
HF Diaphragm:1.4", Type: 1" throat compression driver, Magnet:Ferrite
Crossover 2.1kHz: FIR-X tuning™ (linear phase FIR filter)
Output power Dynamic:1000 W (LF: 800 W, HF: 200 W) / Continuous: 465 W (LF: 400 W, HF: 65 W)
Maximum output level (1m; on axis) 132dB SPL
I/O connectors INPUT1: Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)
Processors D-CONTOUR: FOH/MAIN, MONITOR, OFF
Heat dissipation Fan cooling, 4 speeds
Power requirements 100 V, 100-120V, 220-240 V, 110/127/220V (Brazil), 50/60Hz
Power consumption 74W(1/8 Power Consumption), 18W(Idle)
Cabinet material Plastic
Finish Black
Handle Side x 2
Flying and mounting hardware Bottom x 2, Rear x 1 (Fit for M8 x 15 mm eyebolts)
Pole socket 35mm (Bottom x 1)
Dimensions W 455mm (17.9")
H 700mm (27.6")
D 378mm (14.9")
Net weight 19.3 kg (42.6 lbs)
The Yamaha DBR15 Active speaker is designed to deliver professional-grade audio quality for a variety of applications. Whether you are a sound engineer, a musician, or an event organizer, the DBR 15 offers both reliability and performance. Yamaha is a brand known globally for premium audio equipment, and the DBR 15 is no exception because it embodies the same level of excellence which the brand is renowned for, ensuring you get the best sound experience possible.
The Yamaha DBR15 Active speaker stands out with its high-power output, producing up to 1000 watts of peak power. This makes it suitable for larger venues where louder and more powerful sound is required. But, it’s not just about power; the sound quality is crisp, clear, and well-balanced, so every beat, note, and word is heard distinctly. This makes it perfect for live performances, DJ sets, and public announcements. Because it has versatile input and output options, connectivity is seamless, accommodating various setups and gear, which is crucial for professionals who deal with different audio configurations.
One of the key selling points of the Yamaha DBR 15 Active speaker is its durability and portability. Constructed from high-quality materials, it withstands the rigors of travel and frequent use. Despite its robust build, it remains relatively lightweight, making it easy for one person to carry. And because of its sleek and ergonomic design, it can be easily integrated into any indoor or outdoor setup without looking out of place. Additionally, the DBR 15 features Intelligent Dynamic Control (IDC), a technology that ensures the speaker delivers maximum performance by protecting it from overloading, which prolongs its lifespan and maintains sound consistency.
The Yamaha DBR 15 also includes a 2-channel onboard mixer. This mixer allows for easy control of your audio inputs, making setups quick and efficient, especially in scenarios with minimal setup time. The mixer has a dedicated microphone and line-level inputs, and it can manage signal blending effortlessly. This makes it extremely versatile, whether you're performing live music, hosting an event, or needing a high-quality audio solution for a conference. Because these features are user-friendly, even those with limited technical knowledge can operate the DBR 15 efficiently, making it an excellent choice across various skill levels.
